Full Specifications:

General

General type
A3 Colour Multifunctional for up to 12″ × 18″ format

Engine speed
Up to 35 ppm (A4, colour & B/W), up to 17 ppm (A3)

Warm-up time
Approx. 18 seconds or less

Power consumption
Printing/Copying: 590 W; Ready: 40 W; Sleep mode: 0.4–0.5 W



Paper Handling

Input capacity
Dual 500-sheet trays + 150-sheet multi-purpose tray; auto-selection/switching

Max. input capacity with options
Up to 7,150 sheets

Duplex unit
Standard stackless duplex; supports 60–256 g/m² (statement to 12″×18″)

Output capacity
Standard: 500 sheets face down; Max: up to 4,000 sheets

Document processor
Optional Dual‑Scan Document Processor, nominal capacity 320 sheets



Print

Processor
ARM Cortex‑A53, quad‑core, 1.6 GHz

Fonts
93 outline fonts (PCL6), 136 fonts (KPDL3), and 1 Bitmap font

Features
Encrypted PDF direct print, IPP, email printing, WSD, secure printing via SSL/IPsec/SNMPv3, quick copy, proof & hold, private print, job storage/management, Super Resolution (as listed in extended spec sheets)

Applicable OS (Print)
Windows (8.1, 10, Server 2012/2016/2019/2025), macOS X v10.0+, Chrome OS



Copy

Copy Max. original size
11″ × 17″ (A3/Ledger)

Continuous copy
1-9,999

Zoom range
25 – 400% in 1% Step Increments

Preset magnification ratios
Full Size, 4 Reduction, 4 Enlargement Preset Ratios

Image adjustments
Text, Photo, Text/Photo, Graphic/Map

Digital features
Auto Magnification, Auto Paper Select, Auto Start, Auto Drawer Change, Interrupt Copy, Positive / Negative Reverse, Mirror Image, Rotate Copy, Border Erase, Combine Copy, Split Copy, Electronic Sort, Margin Shift, Page Number, Form Overlay, XY Zoom, Prevent Bleed Through, Text Stamp, Bates Stamp, Blank Page Skip, Specified Color Removal, Proof Copy, Preview, ID Card Copy





Scan

Scan functionalities
Scan to Folder (SMB), Scan to Email, Scan to FTP, Scan to FTP over SSL, Scan to USB, WSD Scan, TWAIN Scan, DSM

Scan speed
Up to 100 ipm simplex / 200 ipm duplex

Scan resolution
600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi

Max. scan size
11″ x 17″

Scan File type
TIFF, JPEG, XPS, OpenXPS, PDF (MMR/JPG Compression/High-Compression PDF); optional Searchable PDF (OCR), MS Office File (option)



Fax

Compatibility
G3 Fax

Modem speed
33.6 Kbps

Scanning speed
Scanning ≤ 2.0 sec; Transmission ≤ 3 sec (JBIG)

Fax Max. Original size
Up to A3 / Ledger; banners up to ~1,600 mm

Fax features
Network fax, duplex, encrypted transmission, polling, broadcast, mailbox, remote diagnostics, optional Internet-fax, dual fax system





Options:

• Paper Feeder 550 sheets with 75 g/m²

• Large Capacity Paper Feeder 2 × 1,500 sheets with 75 g/m²

• Cabinet for 2-drawer configuration
