General type
A3 Color MFP (up to 12″ x 18″)
Engine speed
40 ppm b&w / 40 ppm color
Warm-up time
17 sec. or less
Power consumption
Printing/Copying: 680W in b&w and color
Ready: 45W
Low Power mode: 40W
Sleep mode: 0.5W or less
Input capacity
Dual 500 sheet trays, 150 sheet MPT, auto selection / switching
Max. input capacity with options
7,150 sheets
Duplex unit
Standard stackless duplex supports statement (5.5″ x 8.5″) to 12″ x 18″, 16 lb bond – 142 lb index (60 – 256gsm)
Output capacity
500 sheets face down standard; Max. up to 5,000 sheets with optional finishers
Document processor
Optional Dual Scan Document Processor: 320 sheets
Processor
ARM Cortex-A53 Quad Core 1.6 GHz
Fonts
93 outline fonts (PCL), 136 fonts (KPDL3), 8 fonts (Windows Vista), Calibri, Cambria, 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Features
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality
Applicable OS (Print)
All current Windows operating systems, macOS v10.9 or higher, Unix, Linux, Chrome OS, as well as other operating systems on request
Copy Max. original size
A3, Ledger
Continuous copy
1–9,999
Zoom range
25–400% in 1% steps
Preset magnification ratios
5 Reductions/5 Enlargements
Image adjustments
Text + Photo, Photo, Text, Map, Printed document
Digital features
Scan-once-copy-many, electronic sort (collate), ID card copy, 2in1, 4in1, auto cassette change, skip blank page, margin shift, booklet copy, cover mode
Scan functionalities
Scan-to-email, Scan-to-FTP, Scan-to-SMB 3.0, Scan-to-USB Host, Local/Network TWAIN, WIA, WSD scan
Scan speed
Up to 274 ipm (A4, duplex, 300 dpi, b/w and colour)
Up to 137 ipm simplex
Scan features
Integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Scan resolution
600, 400, 300, 200 dpi (256 grey scales per colour); up to 1,200 dpi via TWAIN/WIA
Max. scan size
A3 / Ledger; banner scanning supported up to 1,900 mm
Scan File type
TIFF, PDF, PDF/A, JPEG, XPS, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, MS Office file and Searchable PDF (optional Scan Extension Kit required)
Compatibility
ITU-T Super G3
Modem speed
Max. 33.6 kbps
Scanning speed
Approx. 3 seconds or less
Scanning density
(Lighter) -4 – +4 (Darker)
Fax Max. Original size
A3 / Ledger
Fax features
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast, memory reception, Internet fax (optional)
