Full Specifications:

General

General type
Monochrome multifunctional for A3 format

Engine speed
Up to 50 pages A4 per minute in b/w
Up to 25 pages A3 per minute in b/w

Warm-up time
Approx. 17 seconds or less

First print / copy time
Approx. 4.3 seconds or less (print, b/w)
Approx. 3.7 seconds or less (copy, b/w)

Power consumption
Print/Copy: 660 W or less
Ready mode: ~40 W or less
Sleep mode: ~0.4 W or less



Paper Handling

Input capacity
Multi-purpose tray: 150 sheets 52 – 300g/m2, (Banner 136–163 g/m2 ) A6R – SRA3 (320 x 450 mm), Custom (98 x 148 to 320 x 1,220 mm), Banner max. 304.8 x 1,220 mm Standard universal paper cassette: 2 x 500 sheet 52 – 300g/m2 Upper cassette A6R up to A4R, lower cassette A6R up to SRA3

Max. input capacity with options
7,150 sheets A4

Duplex unit
Standard 60 to 256 g/m2 SRA3 to A6R

Output capacity
Standard 500 sheets face-down, Max. 5.000 sheets

Document processor
Optional



Print

Processor
ARM A53 (Quad Core) 1.6GHz

Fonts
93 outline fonts (PCL), 136 fonts (KPDL 3), 4 fonts (Calibri), 4 fonts (Cambria), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)

Features
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec,SNMPv3, quick copy, proof and hold, private print, job storage functionality

Applicable OS (Print)
All current Windows operating systems, Mac OS X Version 10.9 or higher, UNIX, LINUX, Chrome OS and as well as other operating systems on request.



Copy

Copy Max. original size
A3, Ledger

Continuous copy
1-9,999

Zoom range
25 – 400 % in 1% steps

Preset magnification ratios
5 Reductions/5 Enlargements

Image adjustments
Text + Photo, Photo, Text, Diagram/Map

Digital features
Scan-once-copy-many, electronic sort, 2in1, 4in1, image repeat, page numbering, cover mode, booklet copy, interrupt copy, form overlay, margin shift, auto cassette change, skip blank page, ID copy





Scan

Scan functionalities
Scan-to-E-Mail, Scan-to-FTP, Scan-to-SMB, Scan-to-USB-Host, Scan-to-Box, TWAIN (Network), WSD(WIA)Scan, DFS Scan, DSM Scan, Mopria Scan

Scan speed
Up to 274 images per minute in black and white and colour (A4, 300 dpi, duplex, with DP-7160/DP-7170)

Scan resolution
600dpi x 600dpi , 400dpi x 400dpi , 200dpi x 400dpi , 300dpi x 300dpi , 200dpi x 200dpi , 200dpi x 100dpi, 1200dpi x 1200dpi(TWAIN driver, WIA driver only)

Max. scan size
Max. A3, banners up to 1,900 mm with optional document feeder

Scan File type
TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, Searchable PDF (Option), MS Office file (Option)

Original recognition
Text, photo, text + photo, Light Text / Fine Line, optimised for OCR



Fax

Compatibility
ITU-T Super G3

Modem speed
Max. 33.6 kbps

Transmission speed
Max. 3 seconds (JBIG)

Scanning speed
2.0 seconds or less

Scanning density
Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, , 600 x 600 dpi, Halftone: 256 greyscales

Fax Max. Original size
Max. A3, Ledger, Banner: up to 1,600mm

Fax features
Network faxing, rotate transmission, rotate reception, encrypted transmission and reception, duplex fax reception, memory reception, mailbox, remote diagnostics, polling transmission and reception, broadcast, Optional Internet-fax, dual fax with second Fax System



Options:

• Paper Feeder 2 × 500 sheets
• Paper Feeder 1,500-sheet tray (PF-810)
• Side Deck for 3,000 sheets (A4)
• Dual Scan Document Processor 320 sheets
• Reversing Document Processor 140 sheets
• Document Finisher 1,000 or 4,000 sheets
• Booklet and Tri-folding unit
• Job Separator 100 sheets
• Inner Shift Tray 100 sheets
• Banner Paper Guide (10 sheets, up to 1,900 mm)
• Punch Unit (2 or 4 holes)
• Fax System (optional)
• Hard Disk Drive 320 GB / 1 TB
• Gigabit Ethernet, Wireless LAN, and other interface options (may vary by region)
• Storage Cabinet for 2-drawer configuration
