General type
Monochrome multifunctional for up to SRA3 format
Engine speed
Up to 70 pages A4 per minute. Up to 35 pages A3 per minute. Duplex print speed: 70 page per minute, A4. Duplex copy speed: 70 page per minute, A4.
Warm-up time
Approx. 17 seconds or less
Power consumption
Print/Copy: 850 W, Ready mode: 40 W, Sleep-mode: 0.4 W
Input capacity
Multi-purpose tray: 150 sheets 52 – 300g/m2, (Banner 136–163 g/m2 ) A6R – SRA3 (320 x 450 mm), Custom (98 x 148 to 320 x 1,220 mm), Banner max. 304.8 x 1,220 mm Standard universal paper cassette: 2 x 500 sheet 52 – 300g/m2 Upper cassette A6R up to A4R, lower cassette A6R up to SRA3
Max. input capacity with options
7,150 sheets A4
Duplex unit
Standard 60 to 256 g/m2 SRA3 to A6R
Output capacity
Document processor
Optional
Processor
ARM A53 (Quad Core) 1.6GHz
Fonts
93 outline fonts (PCL), 136 fonts (KPDL 3), 4 fonts (Calibri), 4 fonts (Cambria), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Features
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec,SNMPv3, quick copy, proof and hold, private print, job storage functionality
Applicable OS (Print)
All current Windows operating systems, Mac OS X Version 10.9 or higher, UNIX, LINUX, Chrome OS and as well as other operating systems on request.
Copy Max. original size
A3, Ledger
Continuous copy
1–9,999
Zoom range
25 – 400 % in 1% steps
Preset magnification ratios
5 Reductions/5 Enlargements
Image adjustments
Text + Photo, Photo, Text, Diagram/Map
Digital features
Scan-once-copy-many, electronic sort, 2in1, 4in1, image repeat, page numbering, cover mode, booklet copy, interrupt copy, form overlay, margin shift, auto cassette change, skip blank page, ID copy
Scan functionalities
Scan-to-E-Mail, Scan-to-FTP, Scan-to-SMB, Scan-to-USB-Host, Scan-to-Box, TWAIN (Network), WSD(WIA)Scan, DFS Scan, DSM Scan, Mopria Scan
Scan speed
Up to 274 images per minute in black and white and colour (A4, 300 dpi, duplex, with DP-7160/DP-7170)
Scan features
Integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Scan resolution
600dpi x 600dpi , 400dpi x 400dpi , 200dpi x 400dpi , 300dpi x 300dpi , 200dpi x 200dpi , 200dpi x 100dpi, 1200dpi x 1200dpi(TWAIN driver, WIA driver only)
Max. scan size
Max. A3, banners up to 1,900 mm with optional document feeder
Scan File type
TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, Searchable PDF (Option), MS Office file (Option)
Original recognition
Text, photo, text + photo, Light Text / Fine Line, optimised for OCR
Compatibility
ITU-T Super G3
Modem speed
Max. 33.6 kbps
Scanning speed
2.0 seconds or less
Transmission speed
Max. 3 seconds (JBIG)
Scanning density
Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, , 600 x 600 dpi, Halftone: 256 greyscales
Fax Max. Original size
A3/Ledger, Banner max. 1,600 mm
Fax features
Network faxing, rotate transmission, rotate reception, encrypted transmission and reception, duplex fax reception, memory reception, mailbox, remote diagnostics, polling transmission and reception, broadcast, Optional Internet-fax, dual fax with second Fax System
